>> P.324
AssemblyTypeABSATSeriesAbsoluteScaleUnit(slimtype)ABSAT1300Series(resolution0.001/0.01/0.05µmspecifications)•Ahigh-precision,fullyabsoluteassemblytypeslimscalewithexcellentrobustness(contamination)comparedtotheconventionalphotoelectrictypethroughtheuseofanewmeasurementprinciple.(in-housecomparison)•Usesanewstructurethathelpspreventcoolantingressaswellashighlycoolant-resistantdustproofrubbermaterial.Anonsitetypelinearscalewithhigherreliabilitythantheconventionalmodelisprovided.•Highestclassforabsolutescalesofminimumresolution0.001µmhasbeenrealized.•Slimshapemakesspace-savingdesignpossible.(MountingpositioniscompatiblewithAT500-SandAT500-H.)•Supportsvariousmanufacturersʼinterfaces,enablingdiversesystemconfigurations.SpecificationsItemModelDetectionmethodMountingmethodReferencepositionforexpansionduetotemperaturevariationEffectiverangeResolutionMaximumresponsespeedIndicationaccuracy(20°C)ExpansioncoefficientVibrationresistanceShockresistancePowersupplyvoltageMaximumcurrentconsumptionOperatingtemperature/humidityStoragetemperature/humidityHighrigiditytypeABSAT13□□(A)-SMulti-pointelasticfixingOpticallinearencoderCenteroftheeffectivemeasuredlengthHighaccuracytypeABSAT13□□(A)-H3-or5-pointelasticfixing19types:100,200,300,400,500,600,700,800,900,1000,1100,1200,1300,1400,1500,1600,1800,2000,2200mm15types:100,150,200,250,300,350,400,450,500,600,700,750,800,900,1000mm3+3L0/1000(µm)0.001/0.01/0.05µm3,000mm/s≈8x10-6/K2+2L0/1000(µm)≤196m/s2(55to2000Hz)≤343m/s2(1/2sin11ms)≤147m/s2(55to2000Hz)≤196m/s2(1/2sin11ms)AT135□/AT134□/AT134□A/AT138□A/AT137□A/AT130□A:5VDC±10%ABSAT132□:24VDC(DRIVE-CLiQcompliant)AT135□/AT134□/AT134□A/AT138□A/AT137□A/AT130□A:270mA(max.)AT132□:150mA(max.)0to50°C,20to80%RH(non-condensing)-20to70°C,20to80%RH(non-condensing)RelationshipofresolutionandmaximumresponsespeedInterfaceFANUCCORPORATIONMitsubishiElectricCorporationYaskawaElectricCorporationPanasonicCorporationSiemensAGMitutoyoCorporation(ENSIS)Resolution0.001µmResolution0.01µm/0.05µmMaximumresponsespeedmm/s300030003000400300030003000300030003000300030008-37
| <
|
> |
>>
