>> P.112
ABSOLUTEDigimaticIndicatorID-CGXSERIES543̶BoreGageType•Dedicatedtoinsidediametermeasurementwithminimum-valueholdingandtolerancejudgmentfunctions*1.UsetogetherwithaMitutoyoboregage(refertopages08-31to08-48fordetails).•Fivebuttons,statusicons,andclearbuttonindicationsalloweasyoperationandvariousfunctions.•Widedisplayandanalogbargrapharestandardonallmodels.•Uptothreesetsofmastervaluesandupper/lowertolerancevaluescanbestoredtosimplifythemastersetting.•Byusingtheparametersetupkit(optional)andthededicatedsoftware,thefunctionsandtheparameterscanbeconfiguredusingacomputer.*1Tolerancejudgmentresultscannotbeoutput.TipsFordetailsofeachmark,seeIntropage13.543-310B-10Exampleofusewithaboregage(soldseparately)■TheABSOLUTEDigimaticBoreGageABSOLUTEDigimaticBoreGages,whichintegratethedisplaywithaboregagemeasuringunit,arealsoavailable.PleasecontactyourlocalMitutoyosalesoffice.Referto"Optionalaccessories"onpage2-34.2-17
| <
|
> |
>>
