LGHTypeMountingthegageALGHcanbemountedbyinsertingitssteminthemountingholeofadedicatedstandorotherequipment.Recommendedmountingholediameterinfixture:15mm+0.024+0.006StemScrewStemScrewFitureFixture•Themountingholeshallbemachinedparallelwiththedirectionofmeasurement.Cosine-effectmeasurementerrorwilloccurifthegageismisalignedwiththisdirection.•Excessiveforceintighteningthestemwillaffectsmoothspindlemotionandshouldbeavoided.•InapplicationswhereaLGHissubjecttomovement,ensurethatthemountingisdesignedtoavoidthecablebeingdraggedwheninmotion.Precautionsformeasurement:•Tohelpensureaccuracy,allow30minuteswarm-uptimeforthesystemafterpoweringON.•Allowsufficienttimefortemperaturestabilizationforboththegageandworkpiecestobemeasured.•Thoroughlycleanthecontactpointandallsurfacestobemeasuredbeforemeasurementtoavoidaccuracydegradationduetodustorgrease.•Beawareofpossibleoverspeederrorsifthecontactpointisallowedtodropsignificantlyfromsurfacetosurfaceontheworkpiece.Appropriatemeasuringproceduresshouldalwaysbeusedwithdueconsiderationforthepartfeatures.1-70
| <
|
> |
>>
